Magic U Series | 4CH Octa-brid DVR System, 4K Output, 2 HDD slots, eSATA, 4CH Audio, 4MP EX-SDI/HD-TVI Support

Compare
Category:

Description

SPECIFICATIONS

Video
Camera input 4 BNC
Individual HD/Analog selectable Analog, HD-SDI, EX-SDI, TVI, AHD, CVI, IP
Available source Upto 4K IPC
TVI/AHD/CVI 720p25,30/1080p25,30/3MP@18 ~ 30/4MP@12 ~ 30
HD-SDI/EX-SDI 720p25,30/1080p25,30/4MP@25,30
Composite/960H/Mixed
IP Camera Spec ONVIF 2.3, RTSP, H.264, dual stream
use gigabit ethnet hub
IP Camera Num 4
IP Camera Restriction Cannot setup Private ZONE
Cannot support Timestamp
Output 2 HDMI (Main Display or Programmable HD Spot)
1 VGA (Main Display or Programmable HD Spot)
1 Composite (Programmable SPOT)
Audio
Audio input 4 RCA
Output 1 RCA
Sensor In 4 (NC, NO selectable)
Alarm out 1 relay
Operating System Embedded Linux OS
Display
Speed Real Time
Resolution (Pixel) 1280 Γ— 1024, 1280 Γ— 720, 1920 Γ— 1080, UHD
Split screen 1,4
Main Recording
CODEC H.264
Resolution (Pixel) 4MP : 4MP@12 ~ 30, 720p
3MP : 3MP@18 ~ 30, 720p
1080p : 1080p, 720p
720p : 720p, 960 Γ— 540
960H, Composite : 960H, D1
Picture quality 4 steps (Super, High, Medium, Low)
Speed 120fps @ 1080p
Dual Recording
CODEC H.264
Resolution (Pixel) 640 Γ— 360
Playback
Display 1,4
Search mode Calendar, Event ,POS , Panorama, Thumbnail
Speed 120fps
Fast/Slow speed Normal, REW & FF [recorded speed Γ— 2, Γ— 4, Γ— 8, Γ— 16,x32,x64,x1/2,x1/4],
Frame to frame, Pause
Network (Individual setting of resolution, frame rates and picture quality)
Network Interface Gigabit Ethernet
High Resolution (Pixel) 1080p, 720p(3MP@18, 1080p25,30)
720p, 960 Γ— 540 (720p25,30)
960H, D1 (Composite, 960H)
Low Resolution (Pixel) 480 Γ— 256 (1080p25,30)
480 Γ— 256 (720p25,30)
CIF (Composite, 960H)
Speed 40fps @ 1080p
Protocol TCP/IP, HTTP, DHCP
Application Windows 7 / 8 (PC Client system& IE)/MAC
Web Browser Internet Explorer, Safari, Chrome, Firefox
Smart phone App Android, iPhone for live and search
Backup
Interface USB 2.0 Γ— 2
Backup device External HDD and CD/DVD-RW, Network, Thumb Drive
The number of HDD 2 SATA(No capacity limit ;  + 1 eSATA(upto 12bays, No capacity limit ; 8TB or more)
Others
Power Consumption 60W
Operating Temperature 5 ~ 40Β°C(41 ~ 104Β°F)
Relative Humidity Maximum 80% non-condensing
Dimension 13.4(W) Γ— 9.85(D) Γ— 2.37(H) in (340 Γ— 250 Γ— 60 mm)
