Description
FEATURES
- Magic Plus Feature : able to assign IP Camera on a selected channel (Max 4 CH)
- Magic Plus Feature : Real-time 1080p Recording on all channels
- REAL-TIME Recording & Playback in all channels
- Full GUI with Alpha Blending
- Individual Setting of Resolution, Frame Rates & Picture Quality
- Instant Replay
- Digital Zoom (Live & Playback)
- Mouse Control
- Weekly Scheduler with Holiday by 10 min Setting
- Covert, Disable & Private Function of Cameras
- Motion Detection with 576 Area Settings
- Relay Alarm Output
- PTZ Control by RS-485
- Daylight Saving Time and Network Time Setting
- Multi-User Authority up to 8 Users
- De-interlacer upon Live & Playback
- 22 Languages with Full Graphic
- Individual Network Port Setting
- Auto Deletion
- Import and Export the Configuration
- POS Interface
- Dual CODEC Engine for Independent Video Transmission
- Interactive Setup via Network
SPECIFICATIONS
| Video | Camera Input | 16 BNC/Loop out |
| Individual HD/Analog | All Hybrid | |
| Available Source | TVI 720p25,30/1080p25,30/Composite/960H/Mixed | |
| Output | 1 HDMI (Main Display or Programmable HD Spot) 1 VGA (Main Display or Programmable HD Spot) 1 Composite (Programmable SPOT) |
|
| Audio | Audio Input | 16 RCA |
| Output | 1 RCA | |
| Sensor In | 16 (NC, NO selectable) | |
| Alarm out | 2 Relay, 14 TTL | |
| Operating System | Embedded Linux OS | |
| Display | Speed | Real Time |
| Resolution (Pixel) | 1280×1024, 1280×720, 1920×1080 | |
| Screen Split | 1 / 4 / 6 / 8 / 9 / 13 / 16 | |
| Recording | CODEC | H.264 / JPEG for 3G, Dual CODEC |
| Resolution (Pixel) | 1080p, 720p, 960×540 (1080p25,30) 720p, 960×540 (720p25,30) 960H, 720H (Composite, 960H) |
|
| Picture Quality | 4 Steps (Super, High, Medium, Low) | |
| Speed | NTSC : 480fps@720p / 480fps@1080p PAL : 400fps@720p / 400fps@1080p |
|
| Playback | Display | 1 / 4 / 8 / 9 / 13 / 16 |
| Search Mode | Calendar, Event ,POS , Panorama, Thumbnail | |
| Speed | NTSC : 480fps@1080p PAL : 400fps@1080p |
|
| Fast/Slow speed | Normal, REW & FF [recorded speed ×2, ×4, ×8,×16,×32,×64,×1/2,×1/4], Frame to frame, Pause | |
| Network | Network Interface | Gigabit Ethernet x 2 |
| Speed | 180fps@1080p 140fps@1080p |
|
| Protocol | TCP/IP, HTTP, DHCP | |
| Application | Windows 7 / 8 (PC Client system & IE)/MAC | |
| Web Browser | Internet Explorer, Safari, FireFox, Chrome | |
| Smart phone App | MR. Patrol : Android, iPhone for Live & Search | |
| Backup | Interface | USB 2.0 × 3 |
| Backup device | External HDD, CD & DVD-RW, Network, Thumb Drive | |
| The Number of HDD | 4 SATA, 1 eSATA | |
| Others | Power Consumption | 150W |
| Operating Temperature | 5 ~40°C(41~104°F) | |
| Relative Humidity | Maximum 80% non-condensing | |
| Dimension | 16.92(W)×16.53(D)×3.46(H)inches / 430(W)×420(D)×88(H)mm | |
